Electron emitter

High-brightness FEG (X-FEG)

Energy

80 kV, 200 kV

Detectors

Super-X Quad Silicon Drift Detector (SDD) without entrance window (4x30mm2 detector area)

STEM unit with bright-field, dark-field and high-angle annular dark-field (HAADF) detector

Camera

Gatan Ultrascan1000 2k on-axis CCD camera



Resolution

0.24 nm (HR-TEM)
0.18 nm (HAADF-STEM)

Imaging / Spectroscopic methods

 Energy-dispersive X-ray spectroscopy (EDXS)

EDX elemental mapping
